Hilti HKD-TE-CX M12 x 50 ∅15 / M10 3/8” x 30 Setting tool ( long )

Setting tool for long HKD anchors with an integrated SDS Plus (TE-C) stop hammer drill bit

• Connection end: TE-C (SDS-plus)
• Base material: Reinforced concrete, Concrete
• Working mode: Hammer drilling

Features

• Drill holes precisely to the desired depth
• Installation of all HKD anchors with embedment depth above 30 mm
• No need to change tools – drilling and setting can be done with the same tool
• No need to change tools
• Drilling and setting with one tool

Applications

• Installation of Hilti HKD short drop-in anchors for fastening pipes, air ducts and suspended ceilings
• Installation of all HKD anchors with embedment depth above 30 mm
• Fastening air ducts
• Fastening suspending ceilings
• Installing the HKD short drop-in anchor

Technical Data

HKD-TE-CX M12x50 ø15 Setting tool

Connection end: TE-C (SDS-plus)

Base material: Reinforced concrete, Concrete

Working mode: Hammer drilling

Head shape: Multi cutter

Head material composition: Tungsten carbide

Diameter: 15 mm

Product class: Ultimate

HKD-TE-CX M10 3/8"x30 Setting tool

Connection end: TE-C (SDS-plus)

Base material: Reinforced concrete, Concrete

Working mode: Hammer drilling

Head shape: Multi cutter

Head material composition: Tungsten carbide

Diameter: 12 mm

Product class: Ultimate
